Search Parts

Item # R&R
Part No. 		OEM
Part No. 		Description Qty
Req
1 R319487 231-5 Tire - Trac. 9.50 x 16 4 Ply
1 R353173 28-9650 Tube - 9.50 x 16
1 R231-5 231-5 Use R319487
2 R342479 33-0750 Tire - 9.50LX 4 (6 Ply) Goodyear Rib
2 R342480 Tube - 9.50 x 14 Steering
3 R1-6559 1-6559 Bushing - With Housing
3 R6-1030 6-1030 Use R1-6559
4 R3-0348 3-0348 Bushing
5 R12-8140 12-8140 Switch - Key 5 Lead
6 R12-9990 12-9990 Meter - Quartz Hour
7 R18-1520 18-1520 Filter - Fuel
8 R5-0200 5-0200 Hose - Hyd 77
8 R5-0220 5-0220 Hose - Hyd 46
8 R5-0230 5-0230 Hose - Hyd 102
8 R18-2350 18-2350 Hose - Suction
8 R26-8520 26-8520 Hose - Hyd
8 R28-9010 28-9010 Hose - Return 62
8 R36-2480 36-2480 Hose - High Pressure 94
9 R22-8720 22-8720 Seal Kit - Fits Hyd Cylinder
10 R26-8310 26-8310 Bail - Lift 6 Long
10 R28-8720 28-8720 Bail - Lift 15 1/2 Long
10 R28-8730 28-8730 Bail - Lift 12 Long
11 R3-2198 3-2198 S-Hook - Drawbar
12 R5-1706 5-1706 Spring - Drawbar
13 R3-0144 3-0144 Shaft - Lifting Cyl
14 R26-8250 26-8250 Pin - Lift Arm 14 5/8
15 R37-2760 37-2760 Pin - Bail Lift 13 5/8
16 R3-9280 3-9280 Bar - Draw
17 R325-17 325-17 Bolt - Axle
18 R32146-13 32146-13 Locknut - 1/2-13
19 R18-4360 18-4360 Filter - Oil Hydraulic
20 R325-14 325-14 Bolt - Hex Hd 1/2-13 x 3-1/2
21 R3254-4 3254-4 Washer - Lock 1/2 Z Int Star
22 R443118 3217-9 Nut - 1/2-13 Zinc
23 R3-8448 3-8448 Washer - Lift Bail
24 R3296-50 3296-50 Locknut - 3/4-16 Full Hgt
25 R302-5 302-5 Fitting - Grease
