Item # R&R
Part No. 		OEM
Part No. 		Description Qty
Req
Needle Tine Holders
1 R105-1099 105-1099 Needle Tine Holder - 5 Tine 5mm Mt 6
2 R105-1098-03 105-1098-03 Clamp - 5 Tine 5mm Mt 6
3 R85-6540 85-6540 Stud - Drive 12
4 R3296-19 3296-19 Locknut - 1/2-20 12
5 R325-7 325-7 Bolt - Hex Hd Gr 5 12
6 R105-1110 105-1110 Turf Guard - Short Mini Tine Holder 2
6 R105-1111 105-1111 Turf Guard - Long Mini Tine Holder 1

Mini Tine Holders
7 R105-1184 105-1184 Tine Holder 6
8 R325-7 325-7 Bolt - Hex Hd Gr 5 12
6 R105-1110 105-1110 Turf Guard - Short Mini Tine Holder 2
6 R105-1111 105-1111 Turf Guard - Long Mini Tine Holder 1
9 R150691 R&R Only Screw - Set Nyloc 3/8-16 x 3/8 10

3 Tine Holders
10 R105-1036-03 105-1036-03 Tine Holder - 3 Tine 3/4 Mt 6
10 R108-2122-03 108-2122-03 Tine HOLDER,3 Tine 7/8 Mt. 6
11 R105-1038-03 105-1038-03 Clamp - Tine Holder 3 Tine 3/4 Mt. 6
11 R108-2124-03 108-2124-03 Clamp - Tine Holder 3 Tine 7/8 Mt. 6
12 R323-8 323-8 Bolt - Hex Hd 3/8-16 x 1-1/2 24
8 R325-7 325-7 Bolt - Hex Hd Gr 5 18
15 R105-1106 105-1106 Turf Guard - Short 3 Tine Holder 2
15 R105-1107 105-1107 Turf Guard - Long 3 Tine Holder 1
4 Tine Holders
13 R105-1045-03 105-1045-03 Tine HOLDER,4 Tine 3/4 Mt. 6
14 R105-1032-03 105-1032-03 Clamp - 4 Tine x 3/4 Tine Holder 6
12 R323-8 323-8 Bolt - Hex Hd 3/8-16 x 1-1/2 18
8 R325-7 325-7 Bolt - Hex Hd Gr 5 18
15 R105-1104 105-1104 Turf Guard - Short 4 Tine Holder 2
15 R105-1105 105-1105 Turf Guard - Long 4 Tine Holder 1

Overhaul Kits Available
R108-2132 108-2132 Kit - Bearing

See Tire Section for Complete Tire Selection
R70-8500 70-8500 Use 19x10.50-8 (2 Ply) Tire
Tech Note: Front & Rear

Other Parts Available
16 R106-8871 106-8871 Bearing 6
17 R105-0965 105-0965 Bearing - Housing 6
18 R105-0989 105-0989 Belt - Primary - Banded 3V 1
18 R105-0991 105-0991 Belt - Secondary - Banded 4V 1
19 R83-0020 83-0020 Switch - Key 6 Lead 1
20 R251-259 251-259 Bearing-Ball 2
21 R251-311 251-311 Bearing - Ball 24
R100-3620 100-3620 Tine - Solid 5mm x 6.43 In. 10
R100-3627 100-3627 Tine - Solid 10mm x 6 3/8 x 3/4 Mt.
R100-3629 100-3629 Tine - Solid 13mm x 6 3/8 x 3/4 Mt.
R100-3630 100-3630 Tine - Solid 16mm x 6 3/8 x 3/4 Mt.
R100-6434 100-6434 Rod - Battery 1
R100-6435 100-6435 Post - Battery - Stainless 2
R104-0984 104-0984 Tine - Hollow 5/8 x 3/4MT x 5-3/4L
R104-9875 104-9875 Spoon - Hd Se 3/4 x 5 3/4 x 3/4 Mt
R104-9876 104-9876 Spoon - Hd Se 5/8 x 5 3/4 x 3/4 Mt
R104-9877 104-9877 Spoon - Hd Se 7/8 x 5 3/4 x 7/8 Mt 18
R105-1180 105-1180 Tine - Hollow .350x 3/4MT x 6-1/2L
R10-6830 10-6830 Stud - Wheel 1/2-20 x 1 3/4 4
R106-8941 106-8941 Tine - Hol Se .236 x5x.049 60
R106-8943 106-8943 Tine - Hollow 5/8 x 3/4MT x 6-1/2L
R106-8947 106-8947 Tine - Hol Se .350 x6.5x.062
R107-7544 107-7544 Tine - Hol Se .500 x6.5x.062
R108-9128 108-9128 Tine - Hollow Alloy .300 x 4.75 x .058
R108-9130 108-9130 Tine - Hollow Alloy .500 x 4.75 x .058
R108-9133 108-9133 Tine - Hollow Alloy .400 x 5.75 x .058
R108-9167 108-9167 Tine - Hol Se Al .400 x 6.5x.058
R108-9168 108-9168 Tine - Hol Se Al .500 x 6.5x.058
R108-9233 108-9233 Tine - Solid .350 x 4.5 x 3/8 Mt. 60
R256-113 256-113 Bushing - Flanged Adj. Pin 2
R354-79 354-79 Cap-Dust 1
R3-6498 3-6498 Washer - Thrust 1
R76-8640 76-8640 Stud-Traction 1
R77-5320 77-5320 Tine - Solid 5/16x 3/4MTX 3-1/4
R834973 92-7900 Spoon - 3/4 Closed 18
R86-9720 86-9720 Tine - Hollow 3/4 x 7/8MT x 5-3/4L 18
R92-7941 92-7941 Tine - Side Eject 3/4 x 4.75L 18
R98-9311 98-9311 Swivel-Throttle 1
R99-7430 99-7430 Relay 4
R09030 32103-22 Nut - Wing 1/4 2
R100-3633 100-3633 Use R59-3690
R100-3634 100-3634 Use R523472
R104-8300 104-8300 Locknut - 5/16-18 Flanged Y/Zinc
R104-8301 104-8301 Locknut - 3/8-16 Nylon Flanged
R108-9211 108-9211 Use R100-3626
R108-9212 108-9212 Use R100-3627
R108-9213 108-9213 Use R100-3629
R19H3130 322-9 Bolt - Hex Hd 5/16-18 x 1-3/4 1
R218-578 218-578 Fuse - 10 Amp 2
R237-22 237-78 O-Ring 1
R237-30 237-30 O-Ring - Seal
R310266 3256-23 Washer - Flat 5/16 USS 2
R32105-13 32105-13 Screw-Hx Was Hd 10-32 x 3/4 1
R32128-23 32128-23 Nut - Lock Hex Flanged 1/2-13 12
R32128-33 32128-33 Nut - 1/4-20 Flanged Serr 6
R32144-14 32144-14 Bolt - Hex Washer 5/16-18 x 5/8 1
R3220-2 3220-2 Nut - Jam - 5/16-24 1
R322-7 322-7 Bolt - Hex Hd 5/16-18 x 1-1/2 2
R3230-1 3230-1 Bolt - Carriage 5/16-18 x 3/4 2
R3231-25 3231-25 Bolt - Carriage 3/8-16 x 1-1/4 14
R3234-11 3234-11 Screw - Hex Washer Hd 2
R3234-13 3234-13 Bolt - Flanged Hex 1/4-20 3
R3253-4 3253-4 Washer - Lock 5/16 Zinc 1
R325-5 325-5 Bolt - Hex Hd 1/2-13 x 1-1/4
R3296-2 3296-2 Nut- #10 Lock
R3296-29 3296-29 Locknut - 5/16-18 ESNA 1
R3296-53 3296-53 Locknut - 5/8-11 ESNA Yellow 12
R343060 63-8360 Ignition - Key SET/2 2
R400258 323-4 Bolt - Hex Hd 3/8-16 x 3/4 2
R400264 323-7 Bolt - Hex Hd 3/8-16 x 1-1/4 4
R453011 3256-4 Washer - Flat 3/8 SAE Y/Zinc 4
R523472 100-3634 Tine - Hollow 1/2 x 3/4MT x 5-1/2L
R59-3670 59-3670 Tine - Hollow 5/8 x 3/4MT x 4-3/4L
R59-3680 66-9140 Tine - Hollow 1/2
R59-3690 59-3690 Tine - Hollow 3/8 x 3/4MT x 4-3/4L
R62-4600 62-4600 Tine - Hollow 3/4 x 7/8MT x 4-3/4L 18
R80-6990 80-6990 Washer - Hardened 12
RP1471-1 321-6 Bolt - Hex Hd 1/4-20 x 1 2
