Item # R&R
Part No.
OEM
Part No.
Description Qty
Req
R&R Reels Available, Lifetime Guaranteed
1 R26-2400 Reel - 5 Blade 1

R&R Bedknives Available, Lifetime Guaranteed
2 R150453 3-4277 Bedknife - Single Lip 1

R&R Rollers Available
2 R5-3939 5-3939 Use R8-3990
2 R8-3990 8-3990 Roller - Smooth Heavy Duty Tubular Steel 1
2 R1503850 R&R Only Roller - Smooth UHMW Polyethylene 1

R&R Overhaul Kits Available
3 R255-100 Overhaul Kit - Cutting Unit
3 R13-3629 13-3629 Overhaul Kit - Cutting Unit

Other Parts Available
4 R254-79 254-79 Cup - Bearing
5 R5-1457 5-1457 Gear - Main
6 R3-4001 3-4001 Hub - Ring Gear With Rivets
7 R3262-3 3262-3 Rivet - Ring Gear Hub
8 R237-38 237-38 O-Ring - Large
9 R253-101 253-101 Seal - Oil Cover
10 R5-1462 5-1462 Nut - Castle
11 R3272-16 3272-16 Pin - Cotter 5/32 x 1-1/4
12 R3-5002 3-5002 Gasket - Cork Fits Side Case
13 R3-5430 3-5430 Use R47-4060
13 R3-5440 3-5440 Use R47-4060
13 R47-4060 47-4060 Cover - Gear Housing
14 R3255-7 3255-7 Washer - Lock 1/4 Ext Star Z
15 R3252-4 3252-4 Screw - Cover
16 R5-1458 5-1458 Gasket - Insp Plate
17 R5-1460 5-1460 Cover - Inspection Plate
18 R11-8960 11-8960 Screw - w/Washer/Neoprene
19 R3-7445 3-7445 Stud
20 R3-4160 3-4160 Ring - Carrier LH
20 R3-4170 3-4170 Ring - Carrier RH
21 R3-3251 3-3251 Spring
22 R3-3996 3-3996 Retainer - Ratchet Ring
22 R3-3997 3-3997 Retainer - Ratchet Ring
23 R5-1463 5-1463 Gear - Pinion
24 R3-8386 3-8386 Nut - Lefthand Thread
25 R12-1190 12-1190 Gear - Ratchet
26 R252-6 252-6 Bearing - Pinion Gear
27 R3-9116 3-9116 Stud - Ratchet Gear RH Thrd
27 R3-9117 3-9117 Stud - Ratchet Gear LH Thrd
28 R281-3 281-3 Plug - Pipe 1/2
29 R3-7446 3-7446 Stud - Spacer Tube
30 R302-14 302-14 Fitting - Relief
31 R5-1464 5-1464 Handle - Throwout
32 R3283-1 3283-1 Pin - Drive Lock
33 R3-3892 3-3892 Sleeve - Throwout
34 R237-21 237-21 O-Ring
35 R3-3891 3-3891 Finger - Throwout LH
35 R3-3904 3-3904 Finger - Throwout RH
36 R253-102 253-102 Use R5-3820
36 R5-3820 5-3820 Seal - Oil Reel
37 R237-58 237-58 O-Ring - Reel
38 R237-54 237-54 O-Ring - Small
39 R150475 3-6462 Screw - Stainless
39 R150476 57-4910 Screw - Regular
40 R3-4275 3-4275 Shaft - Axle
41 R3296-6 3296-6 Locknut - 3/8-24 ESNA
42 R2-4219 2-4219 Nut - Adjustment Reel Brg
43 R3273-14 23273-14 Screw - 5/16-24 x 1 Skt Hd Cap Zinc
44 R3257-3 3257-3 Key - Woodruff
45 R3-7442 3-7442 Washer - Bottom Bed Bar
46 R3-7443 3-7443 Washer - Top Bed Bar Pivot
47 R5-1461 5-1461 Pivot - Bed Bar
48 R5-3425 5-3425 Bolt - Stainless 7/16-20
49 R254-78 254-78 Bearing
