Item # R&R
Part No. 		OEM
Part No. 		Description Qty
Req
1 R112409 112409 Spade Mount - Fits Smv Sign 1
2 R112410 112410 Sign - Slow Moving Vehicle 1
3 R116653 116653 Carrier Frame Assy - Rear 1
4 R116654 116654 Wing Arm Assy - RH Rear 1
4 R116655 116655 Wing Arm Assy - LH Rear 1
5 R5000622 5000622 Carrier Frame Assy 3
6 R122410 122410 Arm Assy 1
7 R122412 122412 Center Arm Assy 1
8 R163206 163206 Cam - Black 2
9 R163207 163207 Cam - Center Arm 1
10 R163208 163208 Cam Assy - Black 1
11 R163214 163214 Cylinder - Hydraulic 1
11A R500798 500798 Seal Kit - Fits R130210 Cylinder
12 R163217 163217 Cylinder - Hydraulic 2
?12A R503067 503067 Seal Kit - Fits R163217 Cyl 1
13 R269005 269005 Ring - Spacer 1/2 - Green 3
14 R307314 307314 Washer - 1/2 1
15 R3253-3 446130 Washer - Lock 1/4 2
16 R3254-6 446142 Washer - Lock 3/8 2
17 R310266 452006 Washer - Flat 5/16 USS 1
17 R3256-23 452006 Use R310266 1
17 R453009 452006 Washer - Flat 5/16 SAE 1
18 R341942 341942 Washer - 1.5 1
19 R550344 550344 Bushing - Formed 1.5 x 1.625 x 2 4
20 R342028 342028 End Cap 4
21 R342049 342049 Bushing - Formed 1.75 x 1.875 x 2 2
22 R343229 343229 Bushing - Bronze 2
23 R343870 343870 Clevis Pin - 1/2 x 2 6
24 R364140 364140 Bushing 2
25 R346091 346091 Pin - Retainer 3
26 R346190 346190 U-Bolt - 5/16-18 x 2-1/2 1
27 R351419 351419 Spacer 2
28 R363189 363189 Spacer - 1 In. Green 2
29 R363192 363192 Pin - Pivot 2
30 R363194 363194 Pin - Front Lift Cyl 2
31 R363195 363195 Pin - Carrier Pivot 1
32 R363215 363215 Shaft 1
33 R363221 363221 Shaft - 18 1/4 In 1
34 R363229 363229 Roller 1
35 R363230 363230 Roller - Centering 2
36 R363231 363231 Bracket - Black 1
37 R363234 363234 Socket - Mounting - Smv 1
39 R400116 400116 Bolt - Hex Hd 1/4-20 x 1-1/2 2
40 R400184 400184 Screw - 5/16-18 x 3/4 Hex 3
41 R400190 400190 Bolt - Hex Hd 5/16-18 x 1-1/4 GR5 1
42 R400280 400280 Bolt - Hex Hd 3/8-16 x 4-1/2 GR5 2
43 R400370 400370 Bolt - Hex Hd 7/16-20 x 1 GR5 8
44 R400408 400408 Bolt - Hex Hd 1/2-13 x 1-1/2 2
45 R400412 400412 Bolt - Hex Hd 1/2-13 x 2 3
47 R403754 403754 Bolt - Whizlock 1/2-13 x 1-1/2 4
48 R441602 441602 Bolt - Carriage 5/16-18 x 3/4 2
49 R443102 443102 Nut - 1/4-20 Yellow Zinc 2
50 R443106 443106 Nut - 5/16-18 Y/Zinc Plated 4
51 R443110 443110 Nut - 3/8-16 Hex. 2
52 R443118 443118 Nut - 1/2-13 Zinc 6
53 R443818 443818 Nut - 1/2-13 Hex Jam Zinc 2
54 R444718 444718 Nut - 5/16-18 Center Lock YZ 1
55 R446136 446136 Washer - Lock 5/16 Zinc 3
56 R446146 446146 Washer - Lock 7/16 Med. 8
57 R446154 446154 Washer - Lock 1/2 /// R3253-7 8
58 R453011 453011 Washer - Flat 3/8 SAE Y/Zinc 4
59 R453017 453017 Washer - Flat 1/2
60 R453022 453022 Washer - 3/4 SAE 2
61 R453023 453023 Washer - Flat 1/4 2
62 R460028 460028 Pin - Cotter 1/8 x 1 6
63 R460050 460050 Pin - Cotter 3/16 x 1-1/4 2
64 R460052 460052 Pin - Cotter 3/16 x 1-1/2 6
65 R460072 460072 Pin - Cotter 1/4 x 2 1/2 2
66 R460088 460088 Pin - Cotter 3/8 x 2 1/2 2
67 R471219 471219 Zerk - Grease 2
68 R471227 471227 Fitting - Grease 1/4-28 45 Deg 7
