Item # R&R
Part No.
OEM
Part No.
Description Qty
Req

R&R Reels Available, Lifetime Guaranteed
1 R502671 011150 Reel - 6 Blade 1
1 R502672 R&R Only Reel - 8 Blade 1
1 R012619 012619 Use R502675 1
1 R502675 012619 Reel - 10 Blade 1
1 R502676 012618 Reel - 5 Blade 1

R&R Bedknives Available, Lifetime Guaranteed
2 R101250 002819 Bedknife - Single Lip 1/2 1
2 R101250L R&R Only Bedknife - Single Lip Low Cut 7/16 1
2 R101251 R&R Only Bedknife - Double Lip 1/2 1

R&R Rollers Available
3 R009225 009225 Roller 1
4 R700500G R&R Only Roller - Smooth Tubular Steel Regreasable 1
4A R1013902 R&R Only Roller - Smooth UHMW Polyethylene 1
5 R026599 26599 Roller - 1

R&R Overhaul Kits Available
6 R500600 Overhaul Kit - Cutting Unit
6 R009293 Overhaul Kit - Cutting Unit
7 R700505 R&R Only Conversion Kit - Roller
8 R100140 Overhaul Kit - Oil Filled Roller
9 R100165 Overhaul Kit - Roller Roller
9A R101395 R&R Only Overhaul Kit - UHMW Roller
9B R101399 R&R Only Overhaul Kit - UHMW 2 Pc Roller

Other Parts Available
10 R445686 003067 Nut - 3/4-16 Castle 2
11 R460028 003107 Pin - Cotter 1/8 x 1 2
12 R203976 002701 Gear - Main Ductile Steel 2
13 R203975 010322 Wheel - Pawl Carrier 2
14 R460026 010798 Pin - Cotter 1/8 x 3/4 2
15 R315861 002520 Washer 2
16 R316765 002793 Spring - RH 1
16 R316766 002806 Spring - LH 1
17 R009218 009218 Use R153215G 2
17 R153215G 009218 Handle - Release 2
18 R203968 006121 Fork - Release 2
19 R204871 002727 Pawl - Main Gear Ductile 8
20 R460012 003145 Pin - Cotter 3/32 x 3/4 8
21 R315867 002533 Pin - Hardened Pawl 8
22 R472205 002834 Plug - 3/8 2
23 R400406 002924 Bolt - Hex Hd 1/2-13 x 1-1/4 8
24 R009215 009215 Use R108096G 1
24 R108096G 009215 Axle - Main Pgf 1
25 R327676 002050 Tab - Locking 2
26 R009222 009222 Use R204119G 2
26 R204119G 009222 Cap - Hub 2
28 R446154 010734 Washer - Lock 1/2 /// R3253-7 8
29 R203984 009223 Hub - Ground Wheel 2
30 R315967 002741 Seal - Cover 2
31 R407706 002976 Screw - Housing Cover 18
32 R302295 002766 Washer - Fwy 2
33 R331834 002885 Gear - Int. Ductile Steel 2
34 R315978 002767 Sleeve - Bearing 2
35 R315977 002754 Bearing - Int Gear 2
36 R472203 010818 Plug - 1/4 2
37 R315877 002585 Key - Pinion Gear 4
38 R009216 009216 Use R154499G 1
38 R154499G 009216 Housing - Gear LH Fits Pgf 1
38 R009217 009217 Use R154500G 1
38 R154500G 009217 Housing - Gear RH Fits Pgf 1
39 R545515 002912 Stud - Ground Wheel 2
40 R408052 017192 Screw - 12-24 x 1/2 Bind Hd 10
41 R009224 009224 Use R352635G 2
41 R352635G 009224 Cap - Cover 2
42 R315876 002572 Gasket - Insp Plate 2
43 R009228 009228 Use R203986G 2
43 R203986G 009228 Cover - Housing 2
44 R315928 002663 Gasket - Cover 2
45 R444742 008928 Nut - 3/4-16 Gripco Cntrloc 2
46 R315843 002494 Gear - Pinion 2
47&48 R500711 011001 Bearing - With Cup Reel 2
47 R315914 Bearing - Tapered Cone 2
48 R302755 Cup - Bearing. Reel 2
49 R315910 010393 Spacer 1
50 R315872 002546 Seal - Reel 2
51 R315873 008290 Seal - Washer 2
52 R443828 003015 Nut - 5/8 - 18 Hex 2
53 R447224 003106 Washer - Lock 5/8 Int.Star Z 2
54&55 R500264 Stud - With Bushing 2
54 R545723 002637 Bushing - For Backing Stud 2
55 R315909 002611 Stud - Bedknife Backing 2
56 R400266 011075 Bolt - Hex Hd 3/8-16 x 1-1/2 2
57 R444510 010799 Nut - 3/8-16 Sq. 2
58 R315851 002507 Stud - Intermediate 2
59 R328058 002833 Shaft - Roller 1
61 R328062 002859 Seal - Roller 2
62 R500574 002846 Collar - Roller 2
64 R412063 010757 Screw - Sq. Hd. Set 2
65 R459007 003132 O-Ring - Roller 2
66 R009219 009219 Use R500763G 1
66 R500763G 009219 Bracket - Roller LH 1
66 R009220 009220 Use R500764G 1
66 R500764G 009220 Bracket - Roller RH 1
67 R412003 010874 Screw - 1/2-13x1-1/2 Sq Hd 2
68 R446154 010873 Washer - Lock 1/2 /// R3253-7 2
69 R443818 010778 Nut - 1/2-13 Hex Jam Zinc 2
70 R009221 009221 Use R500548G 2
70 R500548G 009221 Handle - Adjusting 2
71 R312794 002481 Plug - Adj. Handle 2
72 R315964 002702 Spring - Friction 2
73 R315966 002728 Spring - Adjusting 2
73 R315844 Spring - Worn Reel 2
74 R315965 002715 Screw - Adjusting Fairway 2
76 R009211 009211 Use R130304G 1
76 R130304G 009211 Backing Bar - Bed Knife 1
77 R400106 002898 Bolt - Hex Hd 1/4-20 x 5/8 2
78 R101270 002963 Screw - Bedknife 7
79 R101271 003080 Nut - Bedknife 7
80 R3254-6 010777 Washer - Lock 3/8 2
84 R461406 003171 Pin - Roll 2
85 R700501 R&R Only Roller End - Regreasable 2
86 R700502 R&R Only Retainer - Grease 2
87 R302-5 R&R Only Fitting - Grease 2
88 R500236 002860 Cylinder - Wheel 2
89 R5-3940 006612 Tube - Roller 1
90 R4-5659 006586 Roller End 2
91 R026597 026597 Shaft - Roller - Fits Lesco 1
92 R253-122 005255 Seal - Inner Roller Assy. 2
93 R253-117 005268 Seal - Outer Triple Lip 2
94 R5-4523 006625 Sleeve - Roller 2
95 R3296-15 006716 Locknut - 3/4-16 Nylon Jam 1
96 R3220-7 010328 Nut - 3/4-16 Jam Zinc 2
97 R012620 012620 Use R203987B 2
97 R203987B 012620 Wheel - 18 Rim 18 OD 2
97 R009203 009203 Use R203992B 2
97 R203992B 009203 Wheel - 17 Rim 17 OD 2
98 R006445 006445 Use R315938B 2
98 R315938B 006445 Disc - 18 Wheel 2
98 R009205 009205 Use R315939B 2
98 R315939B 009205 Disc - 17 Wheel 2
99 R400226 011074 Bolt - Hex Hd 5/16-24 x 1 20
100 R310266 010734 Washer - Flat 5/16 USS 20
101 R444754 011076 Locknut - 5/16-24 Center 20
102 R400436 002950 Bolt - Hex Hd 1/2-20 x 7/8 8
103 R446154 010734 Washer - Lock 1/2 /// R3253-7 8
106 R700132 Tube - 4.80 x 12 1
107 R316482 010406 Tire - 4x20 Semi Pneumatic 2
107 R344137 010563 Tire - 4x17 Semi Pneumatic 2
108 R020158 020158 Use R329120B 4
108 R329120B 020158 Disc - Half 4x17 - 14O.D. 4
108 R009212 009212 Use R336054B 4
108 R336054B 009212 Disc - Half 4x20 - 17 O.D. 4
109 R009213 009213 Use R70097B 1
109 R70097B 009213 Wheel Assy - 4x20 (2 Ea) 20OD 1
110 R400258 011078 Bolt - Hex Hd 3/8-16 x 3/4 12
111 R3254-6 010719 Washer - Lock 3/8 12
112 R443110 011087 Nut - 3/8-16 Hex. 12
113 R400438 010644 Bolt - Hex Hd 1/2-20 x 1 8
114 R446154 010734 Washer - Lock 1/2 /// R3253-7 8
115 R47-7510 R&R Only Washer - Nylon 2
116 R500534 010710 Bearing - With Cup 4
117 R500533 R&R Only Bearing - w/Cup And Ring 2
118 R311957 R&R Only Ring - Nilos 2
119 R453022 003119 Washer - 3/4 SAE 2
