Search Parts

Item # R&R
Part No. 		  Description Qty
Req
1 RS3564470079E1 B-S Engine 18 Hp 1
2 R108-6539 Exhaust Manifold 1
3 RS691613 B-S Gasket-Exhaust 1
4 R2112-11 Use R2412-37 1
4 R2412-37 Clamp - Muffler 1-1/4 1
5 RS498984S B-S Muffler 1
6 R150308 Grille - Muffler - Stainless 1
7 R83-1630-03 Bracket - Muffler 1
8 R101344 Bolt - Hex Hd 5/16-18 x 1-3/4 2
9 R453009 Washer - Flat 5/16 SAE 2
10 RS397630 B-S Deflector-Muffler 1
11 R49-2040 Bolt - Hex Washer 1/4-20 x 3/4 8
12 R3253-3 Washer - Lock 1/4 8
13 R453023 Washer - Flat 1/4 8
14 R150250 Wiring Harness - Versa Green 1
15 R83-2310 Shield - Regulator 1
16 R33113-016 Bolt - Hex Washer M6-1.0 x 12 1
17 R24M7139 Washer - Flat 6mm 2
18 R98-2161 Cable - Battery - Positive 1
19 R83-1150 Cable - Battery Negative 1
20 R14M7303 Nut - 6mm x 1.0 Flanged 1
21 R101526 Bolt - Hex Hd 3/8-16 x 2-1/2 GR5 3
22 R83-1040 Washer - Engine 3
23 R83-1050 Spacer 2
24 R83-1030 Mount - Engine 3
25 R322-3 Bolt - Hex Hd 5/16-18 x 3/4 6
26 R445722 Nut - Serrated Washer 6
27 R324-7 Bolt - Hex Hd 7/16-14 x 1-3/4 GR5 4
28 R3253-6 Washer - Lock 7/16 Zinc 4
29 R3296-39 Locknut - 3/8-16 Nylon 3
30 R85-8120-03 Mounting Plate - Engine 1
31 R83-1060-03 Adapter - Pump 1
32 R3274-7 Screw - Soc Hd Cap 3/8-16 x 1 2
33 R3M41933 Cable Ties - 6IN Bulk - Pack/100 2
34 R2412-94 Clamp - Support - Hose 1/4 1
35 R106-4616 Screw - Spacer 1
36 R3296-29 Locknut - 5/16-18 ESNA 2
