Search Parts

Item # R&R
Part No. 		OEM
Part No. 		Description Qty
Req
R&R Reels Available, Lifetime Guaranteed
1 R94-4356 94-4356 Reel - 8 Blade 1
1 R94-4357 94-4357 Use R94-8037
1 R94-8037 94-8037 Reel - 11 Blade 1
1 R94-8039 94-8039 Use R94-4356

R&R Bedknives Available, Lifetime Guaranteed
2 R150466 63-8600 Bedknife - Super Thick 5/16 1
2 R94-6393 94-6393 Use R150466
2 R62-2500 62-2500 Bedknife - Thick 3/16 1
2 R63-8470 63-8470 Bedknife - Thin 1/8 1
2 R63-8560 63-8560 Bedknife - Super Thin 3/32 1
2 R65-8250 65-8250 Bedknife - Tournament 1/16 1
2 R99-4299 99-4299 Bedknife - Tournament Extended 3
2 R93-4262 93-4262 Bedknife - Micro Cut 1
2 R104-7720 104-7720 Bedknife - Micro Cut Extended 3
2 R94-6392 94-6392 Use R62-2500
2 R93-4263 93-4263 Use R65-8250
2 R93-4264 93-4264 Use R63-8470

Service Tools
R51-0880 Tool - Bedknife Screw

Other Parts Available
7 R150477 57-4910 Screw - Regular 1/2 Long 13
8 R354083 Decal - Danger 1
9 R3256-74 3256-74 Washer - Flat 4
10 R93-2559 93-2559 Bearing 2
11 R33023-00 33023-00 Locknut - ESNA 6mm x 1.0 2
13 R94-8170 94-8170 Bracket - Roller Front 2
14 R95-1617 95-1617 Bolt - Eccentric Front Roller Bkt 1
15 R33125-025 33125-025 Bolt - Carriage M10 x 25 w/Nut 4
16 R33113-012 48-7610 Use R48-7610
16 R48-7610 48-7610 Bolt - Hex Hd Nyloc M6 x 12 2
17 R105-3834 105-3834 Bolt - Shoulder 1
18 R94-2958 94-2958 Stud - Alloy Ball Joint 2
19 R3254-6 3254-6 Washer - Lock 3/8 2
20 R93-2511 93-2511 Bed Bar 1
21 R52-2920 52-2920 Pivot - Bed Bar 1
22 R52-2890 52-2890 Bushing - Flanged 2
23 R62-5510 62-5510 Bushing 2
24 R302-18 302-18 Zerk - Grease Press Style 1
25 R95-1634-01 95-1634-01 Frame - Reel Single Point Adj. 1
25 R93-2500 93-2500 Frame - Fits 3200 1
25 R105-9766 105-9766 Use R93-2500 1
25 R105-9767 105-9767 Frame Assy - Single Point Adj. 1
26 R150485 2410-30 Cap - Protective Bearing Housing 1
27 R94-4545 94-4545 Housing - Bearing 2
27 R105-3825 105-3825 Housing - Bearing RH 1
27 R105-3826 105-3826 Housing - Bearing LH 1
28 R94-4544 94-4544 Spacer - Reel 1
29 R93-2489 93-2489 Bearing - Reel 2
29 R105-3827 105-3827 Bearing - Reel 2
30 R93-2483 93-2483 Use R94-8908
30 R94-8908 94-8908 Seal - Reel 2
30 R105-3824 105-3824 Seal - Reel Double Lip 2
31 R32121-123 32121-123 Pin - Spring Roll 5/16 x 3/4 4
32 R94-1341 94-1341 Bolt - Wheel 4
33 R93-2454 93-2454 Nut - 3/8-16 Tapered 4
34 R302-5 302-5 Fitting - Grease 4
35 R33113-008 33113-008 Bolt - Hex Hd M6-1.0 x 8 2
36 R93-2569 93-2569 Bolt - Hex Washer Nyloc M10 4
37 R94-4507 94-4507 Coupling - Reel 1
38 R32120-37 32120-37 Ring - Internal Retaining Reel 1
39 R93-2477 93-2477 Rod - Grass Shield 1
39 R98-2196 98-2196 Use R93-2477
40 R33115-020 33115-020 Use R48-7770
40 R48-7770 48-7770 Bolt - Hex Hd M10 x 20 2
41 R93-2475 93-2475 Shield - Grass Front 1
42 R93-2891 93-2891 Bushing - Plastic For Bed Bar 2
43 R93-2545 93-2545 Bolt - Pivot 2
44 R33104-040 33104-00 Bolt - Hex Washer M8 x 40 1
44 R94-3489 94-3489 Bolt - Hex Hd M8 x 50 1
45 R93-2516 93-2616 Spring - Pivot Hub Bed Bar 1
46 R93-2512 93-2512 Hub - Pivot LH Bed Bar 1
46 R100-3381 100-3381 Hub - Pivot LH Bed Bar w/R93-7501 1
47 R33124-025 33124-025 Bolt - Carriage M8-1.25 x 25 4
48 R87-7510 87-7510 Use R87-8640
48 R87-8640 87-8640 Washer - Flat 2
49 R33024-00 33024-00 Locknut - 8mm x 1.25 4
50 R93-7501 93-7501 Bushing 2
51 R93-7502 93-7502 Bushing - Flanged Nylon 2
52 R33104-020 33104-020 Bolt - Hex Washer Hd 1
53 R3256-82 3256-82 Washer - Flat 1
54 R93-2522 93-2522 Arm - Spring 1
55 R93-2513 93-2513 Hub - Pivot RH 1
55 R100-3380 100-3380 Hub - Pivot RH Bed Bar w/R93-7501 1
56 R93-2550 93-2550 Handle - Bed Bar Adjustment 1
57 R77-0350 77-0350 Retainer - Bearing 2
58 R257-5 257-5 Washer - Thrust 3
59 R93-2518 93-2518 Housing - Pivot 1
60 R93-2562 93-2562 Spring - Bed Bar Adj 1
61 R36-7260 36-7260 Bar - Cut Off Grass Shield 1
62 R93-2466 93-2466 Shaft - Rear Roller 1
63 R93-2523 93-2523 Adjusting - Assy Height of Cut 2
63 R95-1633 95-1633 Adjustment - Hoc 2
64 R95-1638 95-1638 Bracket - Hoc Adj 2
65 R99-8168 99-8168 Collar - Bracket Hoc
66 R33024-00 33024-00 Locknut - 8mm x 1.25 2
67 R33123-016 33123-016 Bolt - Carriage M6 x 20 2
67 R66-3160 33114-020 Bolt - Hex Hd 2
68 R93-2481 93-2481 Shield - Grass Rear 1
70 R33025-00 33025-00 Locknut - 10mm x 1.5 Jam 4
71 R3256-46 3256-46 Washer - Flat 10mm 2
72 R93-2463 93-2463 Roller - Lift 1
73 R93-2464 93-2464 Spacer - Roller 1
74 R33115-080 33115-080 Bolt - Hex Hd M10 x 80 1
75 R94-4543 94-4543 Spring - Flat Reel 2
76 R95-2912 95-2912 Shaft - Roller 1
77 R85-9970 85-9970 Bearing 2
78 R85-7190 85-7190 Washer - Shield 2
79 R99-1460 99-1460 Receiver - Ball Joint 2
80 R32151-12 32151-12 Ring - Retaining 11/16 2
81 R99-4197 99-4197 Shield - Rear Assy 1
82 R99-1456 99-1456 Pad - Wear Grass Shield 1
83 R99-4151 99-4151 Deflector - RH Grass Shield 1
83 R99-4152 99-4152 Deflector - Grass Shield LH 1
84 R60-6500 60-6500 Bolt - Hex Hd M4 x 10 4
89 R150209C 106-6355 Verti-Cut Blade - Carbide Tipped 2mm 36
90 R93-7510 93-7510 Ring - Quad RH Pivot Hub 1
91 R100-6426 100-6426 Reel Motor - Quick Release 3
92 R95-5719 95-5719 Blade - Groomer 41
93 R70-1350 70-1350 Spacer - 1/4 Fits Groomer Shaft 84
94 R95-0728 95-0728 Belt - Fits Groomer 1
95 R104-2067 104-2067 Spacer - End - Motor 2
96 R95-1642-01 95-1642-01 Counterweight 1
97 R100-7113-01 95-7113-01 Counterweight 1
98 R94-8169 94-8169 Decal - Front Roller Bkt Position 2
99 R453011 3256-24 Washer - Flat 3/8 SAE Y/Zinc 2
